XFJ type reaction agitator


Sample download XFJ type reaction mixer. The XFJ type reaction mixer (also known as a box-type mixer) is generally used in flocculation reaction tanks in waterworks (municipal sewage treatment plants) to promote collisions between smaller colloidal particles in the water, adsorption, and gradual formation of flocs of a certain size, so that most of the flocs are retained in the sedimentation tank when the water enters the sedimentation tank. The mixing intensity and mixing time are key factors determining the flocculation effect. The mixing intensity (i.e., the mixing velocity gradient G) in the flocculation tank decreases gradually, and the linear velocity at the center of the impeller blades of each stage gradually slows down, and sufficient mixing time is required to complete the flocculation process.

Keywords: pretreatment equipment, aeration equipment

Product Description

XFJ Type Reaction Stirrer

  XFJ type reaction stirrers (also known as box-type stirrers) are generally used in flocculation reaction tanks in waterworks (municipal wastewater treatment plants) to cause smaller colloidal particles in the water to collide, adsorb, and gradually form flocs of a certain size, so that most of the flocs are retained in the sedimentation tank when the water enters the sedimentation tank.
Stirring intensity and stirring time are key factors determining flocculation efficiency. The stirring intensity (i.e., the stirring velocity gradient G) in the flocculation tank decreases gradually, the linear velocity at the center of the impeller blades of each stage gradually slows down, and sufficient stirring time is required to complete the flocculation process.
The flocculation stirrer can meet the requirements of flocculation laws, so that different sections have different stirring intensities during flocculation, and can adapt to changes in water volume and temperature. The advantages are small head loss, simple tank structure, and convenient additional energy combination.
After the flocculation stirrer is equipped with stepless speed regulation, the stirring intensity can be adjusted according to the changes in water volume, raw water turbidity, and chemical dosage, achieving satisfactory flocculation effect and saving chemical dosage.
Its characteristics:
 Convenient operation and reliable operation;
 Small head loss and simple tank structure;
 Water-lubricated bearings are durable and reliable sealing;
 Low operating speed and low noise.
Working principle
  The motor reducer drives the stirring shaft and paddle to rotate through the coupling, causing smaller colloidal particles in the water to collide, adsorb, and gradually form flocs of a certain size, so that most of the flocs are retained in the sedimentation tank when the water enters the sedimentation tank.
