XFHG-type Reverse-Draw Grating Cleaner
Keywords: pretreatment equipment, aeration equipment
Product Description
The XFHG-type bar screen cleaner is typically used as a medium- and coarse‑grit screening device and serves as an improved, replacement alternative to rotary bar screens.
XFHG-type bar screens are widely used at intake structures or upstream of pumping stations in water supply, wastewater treatment, municipal, and hydraulic engineering projects, particularly in applications with substantial sediment deposition. Their function is to remove large floating debris—such as tree branches, plastic bags, and animal carcasses—from the incoming water, thereby ensuring the reliable and continuous operation of downstream equipment.
Our company’s XFHG‑type grille has passed inspection by the relevant authorities, with certificate number YJ1090065. The applicable standard for the inspection is HJ/T 262‑2006, “Technical Requirements for Environmental Protection Products: Grille-Type Trash Rakes.”
Its characteristics:
● Equipped with both mechanical and electrical overload protection devices, ensuring safe and reliable operation;
● Unloading of slag is accomplished by altering the operating trajectory, delivering excellent results.
● Grating gap specifications are available in a variety of sizes to meet the requirements of different processes;
● High-strength tooth rake, made of stainless steel;
● Factory‑tested as a complete unit, easy to install.
Working principle
The rake teeth are fixed to a chain, which travels along a guide rail. The rake descends from the rear of the bar screen, moving from the bottom toward the front, and lifts the floating debris trapped by the bars upward along the baffle to the discharge chute, where it is discharged into a grit‑removal cart.
The control system operates in fully automatic mode, enabling timed start-up and shutdown, or automatic operation based on the water level differential between upstream and downstream via a differential pressure transmitter. In the event of an overtorque condition, the system promptly triggers an alarm and immediately shuts down automatically, ensuring continuous operation even without on-site supervision.
